Equipment

Unique equipment coupled with technical expertise allows McStarlite to provide some of the most complex “deep drawn” and “bulge formed” parts in today’s forming industry. The presses, many of which were built by McStarlite, range from a small 30 ton press to the larger 2500 ton press with a draw bed of 12 by 12 feet. Whether modifying existing equipment or building new equipment, McStarlite has demonstrated a willingness to partner with the customer to meet almost any requirement.

Deep Draw Presses

2500 Ton Hydraulic Press.12’ sq x 9’ opening, 60” stroke
2000 Ton Hydraulic Press.8’ sq x 50” opening, 24” stroke
1000 Ton Triple Action Hydraulic Press.14’ x 9’ opening, 60” stroke
850 Ton Hydraulic Press.36” x 36” x 53” opening, 48” stroke
500 Ton Hydraulic Press.48” x 48” x 70” High Speed

30, 50, 100, 200, and 400 Ton Mechanical and Hydraulic Presses

McStarlite has the largest deep draw press in the world for a small business.

Bulge Form Presses

2000 PSI x 16’ x 74”.Kontour-X Bulge Press
1500 PSI x 12’ x 54”.Kontour-X Bulge Press

Machines Designed and Built By McStarlite

CNC Machines

Zimmerman FZ30 5 Axis CNC Machining Center.   236″ x 132″ x 59″, 25,000rpm
Anderson 5 Axis CNC Machining Center.Twin Moving Tables, 62” x 122” each
Stratos Pro XL, 3-Axis Gantry.125” x 122”, 18,000rpm



McStarlite has a large amount of General Fabrication Equipment that is used to make their products including Lathes, Mills, Grinders, Drills and a 20′ x 12′ x 9′ Heat Treat Oven
